Laboratory Mini Refrigerated High Speed Desktop Centrifuge PM20R

16214999141 - Laboratory Mini Refrigerated High Speed Desktop Centrifuge for COVID-19 Test PM20R

Microprocessor control with AC Brushless Motor
CFC free cooling system with pre-cooling function.
5 Inches Colorful LCD Display the parameters of speed,timer, RCF, Temperature, rotors information, Program (Memory)information, Acceleration& Deceleration information and Error code information.
Steel centrifuge body and 304# stainless steel chamber are autoclavable and resistant detergents and disinfection liquids.
Gas hinge for lid drop protection.
SafetyElectrical lid interlock, door could not open when rotor is running and machine won’t run when lid open and error code appears.

Get a Quick Quote

Product Details Rotor Details Contact Us

Features:

Emergency lid lock release when power failure
Window on lid for speed calibration and noise measurement.
Continuous operation, working continuously according to the set time.
10 kinds of Program(Memory) and 10 kinds of Acceleration & Deceleration for choice. For more programs please specially mentioned when placing the order.
Automatic troubleshooting with an indication of error code and alarm on the screen.
Wide choicesof rotors are autoclavable.
With CE and ISO9001:2008, ISO13485 certificate

Laboratory Mini Refrigerated High-Speed Desktop Centrifuge PM20R Specification:

Speed range(rpm)	0-20000rpm adjustable
Max Capacity(ml)	4*100ml
RCF range (xg)	0-27800xg adjustable
Noise(dBA)	≦58dB(A)
Time range	1-99minutes adjustable
Temperature range(℃)	-20℃~+40℃ adjustable
Speed accuracy	±20r/min
Temperature accuracy	±2℃
Dimension(mm)	620500350mm
Net weight (without rotor)	75KGS
Power supply	AC220-240V,50/60HZ,10A,0.8KW

Rotor List Details
Rotor Number	Image	Max Speed	Max Volume	Max RCF	Adapter
NO.1 Fixed rotor		20000rpm	12×0.5ml	20380xg	12×0.2ml
NO.2 Fixed rotor		20000rpm	12×1.5/2.2ml	27800xg	12×0.2ml
NO.3 Fixed rotor		16000rpm	24×1.5/2.2ml	23800xg	24×0.2ml
NO.4 Fixed rotor		16000rpm	48×0.5ml	21900xg	48×0.2ml
NO.5 Fixed rotor		16000rpm	10x5ml	17780xg	10×0.2ml 10×0.5ml 10×1.5/2.2ml
NO.6 Fixed rotor		15000rpm	12x10ml	19910xg	12×0.2ml 12×0.5ml 12×1.5/2.2ml
NO.7 Fixed rotor		11000r/min	10x15ml(conical bottom)	13960xg	10×0.2ml 10×0.5ml 10×1.5/2.2ml
NO.8 Fixed rotor		11000r/min	12x15ml(round bottom)	13960xg	12×0.2ml 12×0.5ml 12×1.5/2.2ml
NO.13 Fixed rotor		13000rpm	6x50ml	18550xg	6×0.2ml 6×0.5ml 6x5ml 6x10ml 6x15ml 6x20ml 6x30m 6×1.5/2.2ml
NO.14 Fixed rotor		11000rpm	4x100ml	13280xg	4×0.2ml 4×0.5ml 4x5ml 4x10ml 4x15ml 4x20ml 4x30m 4×1.5/2.2ml
NO.15 Swing rotor		4000r/min	2x2x48 well	1505xg	All can be custom made
